VMRTH Series Heavy Duty Rotary Tiller
VMRTH Series Heavy Duty Rotary Tiller
The VMRTH Series Heavy Duty Rotary Tiller is engineered for 55-115 HP tractors, offering exceptional performance for large-scale farming and heavy-duty soil preparation tasks. Its robust construction and advanced design make it ideal for demanding agricultural operations, providing deep tilling and efficient soil cultivation.
Specifically designed for 55-115 HP tractors, making it suitable for heavy-duty agricultural machines, ensuring optimal performance in large fields.
Built for intensive tasks, the heavy-duty construction ensures durability and reliability even under challenging conditions.
Features big flanges with 6 blades per flange, providing powerful and thorough tilling for deep soil penetration and preparation.
Reaches a maximum working depth of 20cm, making it ideal for deep tilling to enhance soil aeration, structure, and fertility.
Operates at a rotary speed of 232 RPM, delivering fast and efficient tilling for consistent results across various soil types.
Equipped with a side gear drive system, ensuring efficient and reliable power transmission, reducing maintenance needs and increasing durability.
Made from high-strength materials to handle heavy loads and extended use, ensuring a long lifespan in demanding environments.

Application
Large-Scale Farming: Perfect for preparing large agricultural fields for planting, seeding, or crop rotation.
Deep Soil Cultivation: Designed for deep tilling to improve soil health and aeration.
Heavy-Duty Tasks: Ideal for challenging soil conditions such as clay or rocky terrains.
Landscaping: Suitable for large-scale landscaping projects that require heavy-duty soil preparation.


Model | VMRTH190 | VMRTH200 | VMRTH210 | VMRTH220 | VMRTH230 | VMRTH240 | |
---|---|---|---|---|---|---|---|
Work Width | mm | 1900 | 2000 | 2100 | 2200 | 2300 | 2400 |
in | 75 | 79 | 82 | 86 | 90 | 94 | |
PTO Speed | RPM | 540 | 540 | 540 | 540 | 540 | 540 |
Flanges | Number | 7 | 8 | 8 | 9 | 9 | 9 |
Blades | Number | 42 | 48 | 48 | 54 | 54 | 54 |
Tilling Depth | mm | 100-200 | 100-200 | 100-200 | 100-200 | 100-200 | 100-200 |
in | 4-8 in | 4-8 in | 4-8 in | 4-8 in | 4-8 in | 4-8 in | |
Match Power | HP | 55-65 | 65-75 | 75-85 | 85-95 | 95-105 | 105-115 |
Weight | KG | 410 | 440 | 470 | 500 | 530 | 570 |

STANDARD
- Normal Cat.1 PTO Shaft 6-6 Spline
OPTIONS
- Clutch-Type Cat.1 PTO Shaft 6-6 Spline
