VMHR Series 105-150cm Excavator Flail Mower – Hydraulic Flail Heads

Short Description:

The VMHR Series Flail Mower combines robust construction, advanced hydraulic technology, and user-friendly features to deliver excellent mowing performance across a wide range of applications.


  • Driving Type: Direct Hydraulic Drived
  • Cutting Width: 1050-1500 mm
  • Match Excavator: 5.5-12 T

Content details

VMHR Series 105-150cm Excavator Flail Mower – Hydraulic Flail Heads

The VMHR Series Excavator Flail Mower is a versatile and efficient tool designed for irrigation cutting and weed management in gardens and shrubs. It is compatible with excavators of varying tonnage and sizes, capable of adapting to diverse working ranges. With its novel and reliable structure, energy-efficient operation, and ease of use, the VMHR Series is the ideal choice for garden and shrub maintenance.

Key Features:

Reinforced Frame:Built with internal and external reinforcements for exceptional durability and reliability.

Self-Leveling Mechanism:Equipped with a parallelogram device that ensures self-leveling and can be mechanically locked for precision tasks.

Hydraulic Components:Pressure Relief and Anti-Cavitation Valve: Protects the hydraulic system. 3-Way Flow Control Valve: Pressure-compensated for stable output flow, calibrated to match motor speeds with precision. Hydraulic Pipes Protection: Spiral protection (1.6m) for added durability.

Hydraulic Gear Motor:Imported Italian brand with high working pressure (up to 30 bar). High-speed operation (3500rpm) with advanced shaft seal design for high-temperature resistance and reduced oil leakage.

Direct Drive System:The hydraulic motor directly drives the cutter shaft for compact, efficient mowing performance.

Adjustable and Protective Features:Rear adjustable roller for precision cutting height control. Abrasion-resistant rubberized front and rear protections for safety and durability.

Connector Floating Device:Four-bar linkage mechanism allows the mowing head to float with the terrain, preventing damage and ensuring consistent mowing. Lockable for straight work when pruning or fence branch trimming.

Bearings:The mower shaft rotary support bearing uses imported SKF bearings for enhanced load capacity, reduced noise, and extended service life.

Excavator Flail Mower


Technical Parameters
ModelVMHR 105VMHR 125VMHR 150
Length x Width x Heightmm1271×830×6361467×830×6361721×830×636
Cutting widthmm105012501500
Feet3.54.15
Tool shaft diametermm412
Inch16.2
Number of Y-BladesPC364456
Long Hoe Blade quantityPC182228
Short Hoe Blade quantityPC\18\
Total WeightKg296348400
Speed control valve flowLPM60-80
GPM16-21
Tool shaft speedRpm2600-3500
Fixed work stressBar220
Maximum allowable pressure of return oilBar20
Maximum cutting diameter of Y-bladecm Inch4 / 1.6
Long hoe knife Maximum cutting diametercm Inch6 / 2.4
Short hoe knife Maximum cutting diametercm Inch8 / 3.1
Roller diametermm152
Inch6
Driving TypeHydraulic motor direct drive
Adapt to the tonnage of the excavatorT5.5-105.5-108.0-12
